Goodrive300-01A-RT series integrated machine Product dimensions
-101-
A.4 Flange installation dimensions
Figure A-4 Flange installation diagram
Table A-2 Flange installation dimensions (unit: mm)
Power
W1
W2
W3
W4
H1
H2
H3
H4
D1
D2
Diameter
of
mounting
hole
Screw
specification
7.5kW
170
131
150
9.5
292
276
260
6
167
84
6
M5
11kW15kW
191
151
174
11.5
370
351
324
12
196.5
113
6
M5
22kW
266
250
224
13
371
250
350.5
20.5
184.5
104
6
M5
30kW37kW
316
300
274
13
430
300
410
55
202
118.5
6
M5
Note: Flange mounting plates are often required for flange installation.
