INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Communication protocol
-150-
Function
description
Address
definition
Data meaning
R/W
characteristics
=10: communication control
VFD fault code
2102H
See fault type.
R
VFD identification
code
2103H
Goodrive300-01A-RT-----0x0130
R
Running
frequency
3000H
Compatible with CHF100A, CHV100
communication address
R
The set
frequency
3001H
R
Bus voltage
3002H
R
Output voltage
3003H
R
Output current
3004H
R
Running speed
3005H
R
Output power
3006H
R
Output torque
3007H
R
Closed-loop
setting
3008H
R
Closed-loop
feedback
3009H
R
Input IO state
300AH
R
Output IO state
300BH
R
Analog input 1
300CH
R
Analog input 2
300DH
R
Analog input 3
300EH
R
External counting
value
3014H
R
The set torque
value
3015H
R
VFD identification
code
3016H
R
Fault code
5000H
R
D.2.5 Error message response
Table D-2 Error message response and meaning
Code
Name
Meaning
01H
Illegal
command
The command from master cannot be executed. The reason maybe:
1. This command is only for new version and this version cannot realize.
2. Slave is in fault state and cannot execute it.
