INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Function description
-77-
P21 group Power-frequency fan protection
Function
code
Name
Description
Default
Modify
P21.00
Rated current of the
fan
0.0–40.0A
This function code is related to current
detection and overload protection function of
power-frequency fan. If P21.00 is set to a
non-zero value, this function is enabled. If
P21.00 is set to 0, this function is disabled.
0.0A
○
P21.01
Current transformation
ratio of the fan
1.0–4000.0
200.0
○
P21.03
Current imbalance
coefficient
1.00–5.00
Among the current of three phases of the
fan, if the ratio between max. current and
min. current is larger than P21.03, the VFD
displays fan current imbalance fault.
3.00
○
P21.04
Calibration coefficient
of A phase current of
the fan
0.0–150.0%
Actual current = Displayed current * current
calibration coefficient
Note: When restoring to default values, this
value will stay in currently set value.
100.0%
○
P21.05
Calibration coefficient
of B phase current of
the fan
100.0%
○
P21.06
Calibration coefficient
of C phase current of
the fan
100.0%
○
P21.07
User-defined fault
action selection 1
Ones: Motor overload (OL1)
0: Coast to stop
1: Runs at alternative frequency of P21.10
Tens: Electronic overload (OL3)
0: Process as per P11.08
1: Run at alternative frequency of P21.10
Hundreds: Rectifier module overheat (OH1)
0: Coast to stop
1: Run at alternative frequency of P21.10
Thousands: Inverter module overheat fault
(OH2)
0: Coast to stop
1: Run at alternative frequency of P21.10
0x0000
○
P21.08
User-defined fault
action selection 2
Ones: Underload (LL)
0: Process as per P11.08
0x0000
○
