Goodrive300-01A-RT series integrated machine RS485 communication LCD keypad
-121-
03.17 16:02:35
Home
Fan State Stop
Return
Fan running info
Temperature xxxxxx
Fan Phase A Display Current xxxx.x A
Fan Phase B Display Current xxxx.x A
Fan Phase C Display Current xxxx.x A
Figure B-31 Fan running information
Note: Master and fan running information is read only and therefore cannot be edited.
B.4.10 Master parameter interface
1. Enter the master parameter interface through the main menu.
03.17 16:02:35
Home
Max Ouput Freq xxx.xx Hz
Return Edit
Master Param
Run Freq Up limit xxx.xx Hz
Run Freq Down limit xxx.xx Hz
Load Run Low Limit Freq xxx.xx Hz
No-load Run Freq xxx.xx Hz
Acc time xxxx.x s
03.17 16:02:35
Home
PID Output Downlimit xxxx.x %
Return Edit
Master param
Prop Gain xxx.xx
Integral Time xxx.xx s
Differential Time xxx.xx s
PID Output Uplimit xxxx.x %
Sample Cycle xx.xxx s
Figure B-32 Master parameter interface
Master parameter
Initial value
Function
Proportional gain
(Kp)
10.00
It indicates the speed of tracking the set working
pressure. A greater value indicates a higher speed
of tracking and easier oscillation. A smaller value
