INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine RS485 communication LCD keypad
-122-
Master parameter
Initial value
Function
indicates a lower speed of tracking and slower
adjustment. The recommended setting range is
5.00–15.00.
Integral time
2.00
The recommended setting range is 2.00–4.00.
Differential time (Td)
1.00
It is used for lag tracking on the large-scale lag
system (such as temperature).
Sampling time (T)
0.100s
It indicates the sampling period for feedback values.
PID output upper
limit
100%
It indicates the upper limit of the output of the PID
regulator.
PID output lower
limit
0.0%
It indicates the lower limit of the output of the PID
regulator. It is set based on the lower limit
frequency.
Max. output
frequency
50.00Hz
It indicates the maximum output frequency of the
VFD.
Upper limit of
running frequency
50.00Hz
It indicates the upper limit of the output frequency of
the VFD.
Lower limit of
running frequency
00.00Hz
It indicates the lower limit of the output frequency of
the VFD.
Loaded running
frequency lower limit
40.00Hz
It indicates the minimum working frequency that is
allowed to output when the pressure exceeds the
set value but does not reach the unloading pressure
during regulation.
Empty-load running
frequency
38.00Hz
It indicates the working frequency when the air
compressor is empty loaded.
ACC time
Model
depended
It indicates the time taken by the VFD to accelerate
from 0Hz to the maximum frequency.
DEC time
Model
depended
It indicates the time taken by the VFD to decelerate
from the maximum frequency to 0Hz.
2. You can edit parameters only after entering a correct administrator password.
