INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Function description
-62-
P14 group Serial communication
Function
code
Name
Description
Default
Modify
P14.00
Local communication
address
1–247; 0 indicates a broadcast address
2
○
P14.01
Communication baud
rate
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
4
○
P14.02
Data bit check
0: No parity check (N, 8, 1) for RTU
1: Even parity (E, 8, 1) for RTU
2: Odd parity (O, 8, 1) for RTU
3: No parity check (N, 8, 2) for RTU
4: Even parity (E, 8, 2) for RTU
5: Odd parity (O, 8, 2) for RTU
1
○
P14.03
Communication
response delay
0–200ms
5ms
○
P14.04
Communication
timeout time
0.0 (invalid); 0.1–60.0s
0.0s
○
P14.05
Transmission error
processing
0: Alarm and coast to stop
1: Do not alarm and continue running
2: Do not alarm and stop as per stop mode
(under communication control mode only)
3: Do not alarm and stop as per stop mode
(under all control modes)
4: Alarm and coast to stop, and automatic
fault reset after communication is restored
0
○
P14.06
Communication
processing action
0x000–0x111
LED ones: write operation action
0: Respond to write operations
1: Not respond to write operations
LED tens: Communication encryption
processing
0: Communication encryption setting is
invalid
1: Communication encryption setting is valid
LED hundreds: Communication CRC check
failure handling
0x000
○
