INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Function description
-45-
Function
code
Name
Description
Default
Modify
28: Solenoid valve control output
29: Cooling fan control of main motor
30: System fault (used for air compressor)
P06.05
Output terminal polarity
selection
The function code is used to set the polarity
of output terminals.
When a bit is 0, the input terminal is positive.
When a bit is 1, the input terminal is
negative.
BIT3
BIT2
BIT1
BIT0
Reserved
TA1-TC1
RO1
Y1
Setting range: 0–0xF
0
○
P06.06
Y1 switch-on delay
0.000–50.000s
0.000s
○
P06.07
Y1 switch-off delay
0.000s
○
P06.10
Solenoid valve
(TA1-TC1) switch-on
delay
0.000s
○
P06.11
Solenoid valve
(TA1-TC1) switch-off
delay
0.000s
○
P06.12
RO1 switch-on delay
0.000s
○
P06.13
RO1 switch-off delay
0.000s
○
P07 group HMI
Function
code
Name
Description
Default
Modify
P07.00
User password
0–65535
0
○
P07.01
Function parameter
copy
0: No operation
1: Uploading function parameters from the
machine to keypad
2: Downloading function parameters
(including the motor parameters) from the
keypad to machine
3: Downloading function parameters
(excluding motor parameters of the P02 and
P12 groups) from the keypad to machine
4: Downloading function parameters (only
motor parameters of the P02 and P12
0
◎
