INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine RS485 communication LCD keypad
-120-
03.17 16:02:35
Home
Invalid
Return Confirm
Auxiliary Temp Protection
Valid
Figure B-28 Auxiliary temperature protection enabling
B.4.9 Running information
Enter the running information interface through the main menu. Running information includes master
running information and fan running information.
03.17 16:02:35
Home
Master
Return Select
Run information
Fan
Figure B-29 Running information interface
03.17 16:02:35
Home
Output Current xxxx.x A
Return
Master running info
Output Voltage xxxxxx V
Motor Speed xxxxxx rpm
Output Freq xxx.xx Hz
Motor Actual Output Power xxxx.x kW
Present Pressure xxx.xx MPa
Figure B-30 Master running information
