INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Function description
-33-
P01 group Start and stop control
Function
code
Name
Description
Default
Modify
P01.00
Start mode
0: Direct start
0
◎
P01.01
Starting frequency of
direct start
0.00–50.00Hz
0.50Hz
◎
P01.02
Starting frequency hold
time
0.00–50.00s
0.00s
◎
P01.03
Braking current before
start
0.0–150.0%
0.0%
◎
P01.04
Braking time before
start
0.00–50.00s
0.00s
◎
P01.05
ACC and DEC mode
0: Linear
0
○
P01.08
Stop mode
0: Decelerate to stop
1: Coast to stop
0
○
P01.09
Starting frequency of
DC braking for stop
0.00–P00.03 (max. output frequency)
0.00Hz
○
P01.10
Wait time before DC
braking for stop
0.00–50.00s
0.00s
○
P01.11
DC braking current for
stop
0.0–150.0%
0.0%
○
P01.12
DC braking time for
stop
0.00–50.00s
0.00s
○
P01.13
FWD/REV running
deadzone time
0.0–3600.0s
0.0s
○
P01.14
FWD/REV running
switching mode
0: Switch at zero frequency
1: Switch at the starting frequency
2: Switch after the speed reaches the stop
speed with a delay
0
◎
P01.15
Stop speed
0.00–100.00Hz
5.00Hz
◎
P01.16
Stop speed detection
mode
0: Detect as per the set speed value (judge
the ramp frequency)
1: Detect as per the speed feedback value
(valid for vector control only)
1
◎
P01.17
Feedback speed
detection time
0.00–100.00s (valid only when P01.16=1)
0.50s
◎
P01.18
Terminal-based
running command
protection at power-on
0: The terminal running command is invalid
at power-on
1: The terminal running command is valid at
power-on
0
○
