Goodrive300-01A-RT series integrated machine Function description
-60-
Function
code
Name
Description
Default
Modify
reporting an underload alarm.
3: The VFD stops running after reporting an
overload/underload alarm.
LED hundreds:
0: Always detect
1: Detect only in constant speed running
P11.09
Overload pre-alarm
detection level
P11.11–200%
G type:
150%
○
P11.10
Overload pre-alarm
detection time
0.1–3600.00s
1.0s
○
P11.11
Underload pre-alarm
detection level
0%–P11.09
50%
○
P11.12
Underload pre-alarm
detection time
0.1–3600.0s
1.0s
○
P11.13
Fault output terminal
action during fault
0x00–0x11
LED ones:
0: Act during undervoltage fault
1: Do not act during undervoltage fault
LED tens:
0: Act during automatic reset period
1: Do not act during automatic reset period
0x00
○
P11.14
Speed deviation
detection value
0.0–50.0%
10.0%
○
P11.15
Speed deviation
detection time
0.0–10.0s (Speed deviation protection is
disabled when P11.15 is set to 0.0.)
0.5s
○
P11.16
Automatic frequency
reduction during
voltage drop
0: Invalid
1: Valid
1
○
P13 group Synchronous motor control parameters
Function
code
Name
Description
Default
Modify
P13.00
Pull-in current
reduction coefficient
0.0–100.0%
SM injection current drop rate is used to set
the reduction rate of the injection reactive
current. When the active current increases to
some extent, the injection reactive current
50.0%
○
