INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Product overview
-7-
Category
Function
Specification
EMC filter
Users can choose the optional external filter
which fulfills the requirements of IEC61800-3
C2.
Note:
 Max. output current of 7.5kW VFD model is 500mA.
 When the input voltage exceeds 440VAC, the power-frequency transformer inside the single
VFD integrated machine will need to be customized.
2.2 Product nameplate
IP20
Model: GD300-01A-7R5G-4-RT
Power(Output): 7.5kW(motor) 0.75kW(fan)
Input: AC 3PH 380V(-15%)-440V(+10%) 25A 47Hz-63Hz
Output: AC 3PH 0V-Uinput 18.5A 0Hz-250Hz(motor)
AC 3PH Uinput 2.5A 47Hz-63Hz(fan)
S/N: Made in China
Shenzhen INVT Electric Co.,Ltd.
Figure 2-1 Product nameplate
Note: This is a nameplate example of a standard model. CE, TUV, and IP20 are marked according to
the actual certification condition.
2.3 Model description
The model code contains product information. Users can find the model code on the VFD nameplate
or simple nameplate.
GD300-01A–7R5G–4–RT
① ②
④
③
Figure 2-2 Product model
Field
Symbol
Description
Content
Abbreviation of product
series
①
Abbreviation of
product series
GD300-01A: Goodrive300-01A VFD for
air compressor
Rated power
②
Power class + Load
type
7R5: 7.5kW
G: Constant torque load
Voltage class
③
Voltage class
4: AC 3PH 380V(-15%)–440V(+10%)
Power-frequency
fan/Built-in transformer
④
Power-frequency
fan/Built-in
transformer
Single-VFD air compressor integrated
machine
R: Built-in relay unit, supporting

INVT Goodrive300-01A-RT Series Specifications

General

Brand	INVT
Model	Goodrive300-01A-RT Series
Category	Inverter
Language	English
