INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Product overview
-6-
Category
Function
Specification
Analog pressure
input
One 4–20mA/0–1.6MPa input
Analog
temperature input
Two PT100 analog temperature inputs;
resolution rate: 1°C; temperature range:
-20°C–150°C; precision error: 3°C
Digital input
Three normal inputs, max frequency: 1kHz
One PTC digital input
Digital output
One Y terminal output
Relay output
One relay output (NO) 250VAC/3A
1 solenoid valve output
Fault protection
function
Over 30 kinds of fault protection functions:
overcurrent, overvoltage, undervoltage,
overtemperature, phase loss, overload, fan
current imbalance, etc.
Fan protection
function
Overload protection: 60s at 120% overload; 48s
at 130% overload; 24s at 150% overload; 8s at
160% overload; 5s at 200% overload; 1s at
300% overload
Current imbalance protection: when any two
phases differ from each other by 60–75%, stop
at fault, action time ≤5s
Output short-circuit protection: the protection
can be implemented by using the internal fuse.
Output short-to-ground protection: the
protection can be implemented by using the
internal fuse.
Solenoid valve
port protection
220V output short-circuit protection
RS485
communication
One RS485 communication
Others
Installation mode
Wall installation, flange installation
Temperature of
running
environment
-10–+50°C; derating is required if the ambient
temperature exceeds 40°C; derate by 1% for
every increased 1°C
Ingress protection
rating
IP20
Pollution degree
Degree 2
Cooling mode
Forced air cooling
