Goodrive300-01A-RT series integrated machine Function description
-65-
Function
code
Name
Description
Default
Modify
P17.26
Current running time
0–65535m
0m
●
P17.28
ASR controller output
-300.0%–300.0% (of the motor rated current)
0.0%
●
P17.29
Magnetic pole angle of
SM
0.0–360.0
0.0
●
P17.30
Phase compensation
quantity of SM
-180.0–180.0
0.0
●
P17.31
High-frequency
superposition current of
SM
0.0%–200.0%
0.0
●
P17.32
Flux linkage
0.0%–200.0%
0.0
●
P17.33
Exciting current
reference
-3000.0–3000.0A
0.0
●
P17.34
Torque current
reference
-3000.0–3000.0A
0.0
●
P17.35
AC incoming current
0.0–5000.0A
0.0
●
P17.36
Output torque
-3000.0Nm–3000.0Nm
0.0Nm
●
P17.37
Motor overload count
value
0–100 (OL1 fault is reported when the count
value reaches 100)
0
●
P17.38
PID output value
Display the output value of PID control of
discharge pressure signal; 100%
corresponds to max. output frequency
P00.03.
Setting range: -100.00–100.00%
0.00%
●
P17.39
Warning code
0–41
Refer to the function description of P07.27.
0
●
P18 group Functions for air compressors
Function
code
Name
Description
Default
Modify
P18.00
Air compressor control
mode
0: Normal VFD mode
1: Air-compressor control mode
Note: When P18.00 is set to 1, P19 group
(Air compressor status viewing) is valid.
0
◎
