INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Function description
-64-
Function
code
Name
Description
Default
Modify
pressure 0.0–P18.04. If P1- input voltage is
larger than 9.8V or less than 1V, it indicates
pressure signal fault occurs.
Range: 0.00–10.00V
P17.20
PT1 input voltage
Display analog input voltage value of PT1
channel. Under air-compressor mode,
connect to PT100 thermal resistor
temperature sensor, different temperature
generates different resistor value, and
different resistor value corresponds to
different input voltages, therefore, the input
voltage value can correspond to
corresponding detection temperature. Input
voltage P18.28–P18.29 corresponds to 20°C
to 120°C.
Setting range: 0.00–10.00V
0.00V
●
P17.22
PT2 input voltage
Display analog input voltage value of PT2
channel. Under air-compressor mode,
connect to PT100 thermal resistor
temperature sensor, different temperature
generates corresponding resistor value, and
different resistor value corresponds to
corresponding input voltage, therefore, input
voltage value can correspond to
corresponding detection temperature. Input
voltage P18.32–P18.33 corresponds to 20°C
to 120°C.
Setting range: 0.00–10.00V
0.00V
●
P17.23
PID reference value
Display the set value of discharge pressure
signal. 100% corresponds to the upper limit
value of discharge pressure sensor
(P18.04).
Setting range: -100.0–100.0%
0.0%
●
P17.24
PID feedback value
Display the detection value of discharge
pressure signal.
Setting range: -100.0–100.0%
0.0%
●
P17.25
Motor power factor
-1.00–1.00
0.0
●
