INVT Goodrive300-01A-RT Series - Page 73

Goodrive300-01A-RT series integrated machine Function description
-67-
Function
code
Name
Description
Default
Modify
pressure during P18.13, the VFD will
perform loaded running again, and pressure
PID will regulate accordingly.
Manual sleep: Conduct manual sleep
through the touch screen or other
communication methods.
P18.02
Loading/unloading
mode
0: Automatic;
1: Manual
When it is set to manual state, after air
compressor starts, it is required to conduct
loading/unloading manually through the
touch screen or other communication
methods. When it is set to automatic mode,
the air compressor loads/unloads
automatically after starting, as shown in
Figure 5-2.
0
○
P18.03
Temperature sensor
channel
0: Machine head temperature PT1, auxiliary
temperature PT2
1: Machine head temperature PT2, auxiliary
temperature PT1
2: Temperature display in normal VFD mode
(P18.00=0) (machine head temperature
PT1, auxiliary temperature PT2)
1
◎
P18.04
Upper limit of pressure
sensor P1
0.00–20.00 Mpa
Related to the actual range of pressure
sensor, the corresponding voltage of P18.04
is P05.34.
Note: When restoring to default value, this
value stays in currently set value.
1.60Mpa
◎
P18.05
Unloading pressure
Under automatic loading/unloading mode,
when air compressor control is valid and the
air compressor supplies air as normal, if the
discharge pressure is higher than P18.05,
unloading automatically. If sleep function is
valid (P18.01=1), the VFD enters sleep
state; if the discharge pressure is lower than
P18.06, loading automatically. P18.07 is
used to set the air-supply pressure when the
0.80Mpa
○
P18.06
Loading pressure
0.60Mpa
○
P18.07
Set pressure
0.70Mpa
○
