INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Function description
-63-
Function
code
Name
Description
Default
Modify
0: Return error type 06
1: Do not return any data
P17 group Status viewing
Function
code
Name
Description
Default
Modify
P17.00
Set frequency
0.00Hz–P00.03
0.00Hz
●
P17.01
Output frequency
0.00Hz–P00.03
0.00Hz
●
P17.02
Ramp reference
frequency
0.00Hz–P00.03
0.00Hz
●
P17.03
Output voltage
0–1200V
0V
●
P17.04
Output current
0.0–3000.0A
0.0A
●
P17.05
Motor speed
0–65535RPM
0 RPM
●
P17.06
Torque current
-3000.0–3000.0A
0.0A
●
P17.07
Excitation current
-3000.0–3000.0A
0.0A
●
P17.08
Motor power
-300.0%–300.0% (relative to rated motor
power)
0.0%
●
P17.09
Output torque
-250.0–250.0%
0.0%
●
P17.10
Estimated motor
frequency
0.00–P00.03
0.00Hz
●
P17.11
DC bus voltage
0.0–2000.0V
0V
●
P17.12
Digital input terminal
status
0000–00FF
0
●
P17.13
Digital output terminal
status
0000–000F
0
●
P17.16
Master fault code
0–43 (see P07.27–P07.32 for details)
0
●
P17.17
Automatic reset count
of hardware
overcurrent
0–3
0
P17.18
Accumulative
automatic reset count
of hardware
overcurrent
0-65535
0
●
P17.19
P1- input voltage
Display analog input voltage value of P1-
channel, 2.00V–10.00V corresponds to
4–20mA; P05.32–P05.34 correspond to
0.00V
●
