INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Function description
-78-
Function
code
Name
Description
Default
Modify
1: Run at alternative frequency of P21.10
2: Normal running
Tens: External fault 1 signal
0: Coast to stop
1: Run at alternative frequency of P21.10
Hundreds: PTC overtemperature signal
0: Coast to stop
1: Run at alternative frequency of P21.10
2: Normal running
Thousands: Solenoid valve overcurrent
signal
0: Coast to stop
1: Run at alternative frequency of P21.10
2: Normal running
P21.09
User-defined fault
action selection 3
Ones: RS485 communication fault (CE)
0: Coast to stop
1: Run at alternative frequency of P21.10
Tens: EEPROM operation fault (EEP)
0: Coast to stop
1: Run at alternative frequency of P21.10
Hundreds: Current overload of
power-frequency fan (OLF)
0: Coast to stop
1: Run at alternative frequency of P21.10
Thousands: 3PH current imbalance of
power-frequency fan (SPOF)
0: Coast to stop
1: Run at alternative frequency of P21.10
0x0000
○
P21.10
Alternative frequency
0.0–100.0% (max. output frequency)
50.0%
○
P21.11
Running time of
alternative frequency
0.0–6000.0s
Note: When a user-defined fault occurs to
the VFD and the VFD continues running at
alternative frequency (P21.10), if the fault
persists for more than the time set by
P21.11, the VFD coasts to stop. If the fault
no longer occurs within the time set by
P21.11, the VFD restores to normal mode.
60.0s
○
