Goodrive300-01A-RT series integrated machine RS485 communication LCD keypad
-118-
03.17 16:02:35
Home
Auxiliary Temp Alarm xxxxxx
Return Edit
Protection param
Auxiliary Press Alarm xxx.xx MPa
Auxiliary Temp Proteciton Invalid
Present Auxiliary Temp xxxxxx
Auxiliary Temp Prealarm xxxxxx
Auxiliary Press Prealarm xxx.xx MPa
Figure B-25 Protection parameter interface
When the actual exhaust temperature is higher than this
temperature, a pre-alarm is reported.
When the actual exhaust temperature is higher than this
temperature, an alarm is reported, and the device is stopped.
When the actual air supply pressure is higher than this pressure,
a pre-alarm is reported.
When the actual air supply pressure is higher than this pressure,
an alarm is reported, and the device is stopped.
Auxiliary
temperature
pre-alarm
When the detected temperature is higher than this temperature,
a pre-alarm is reported. This parameter is valid only after it is
enabled in system configuration.
Auxiliary
temperature alarm
When the detected temperature is higher than this temperature,
an alarm is reported, and the device is stopped. This parameter
is valid only after it is enabled in system configuration.
Auxiliary pressure
pre-alarm
When the detected pressure is higher than this pressure, a
pre-alarm is reported. This parameter is valid only after it is
enabled in system configuration.
When the detected pressure is higher than this pressure, an
alarm is reported. This parameter is valid only after it is enabled
in system configuration.
Low temperature
protection
threshold
When the detected temperature is lower than this temperature, a
low temperature pre-alarm is reported. This parameter is valid
only after it is enabled in system configuration.
Current auxiliary
temperature
It displays the auxiliary temperature that is currently detected.
To Next Page
