INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine HMI
-144-
Function
code
Name
Default
Description
direction
P01.15
Stop speed
500
5Hz
P03.27
Speed display
selection in
vector control
1
0: Display the actual value
1: Display the set value
P05.01
Function of S1
6
6: Coast to stop
P05.02
Function of S2
46
46: External fault 1
P05.03
Function of S3
9
9: External fault input
P05.04
PTC signal input
51
51: PTC signal
P05.10
Input terminal
polarity
1
1: Emergency stop terminal is normally closed.
P05.11
Digital input filter
time
0.2000
/
P06.02
RO1 output
29
29: Cooling fan control of main motor
P06.03
Solenoid valve
output (TA-TC)
28
28: Solenoid valve control output (used for air
compressor)
P09.00
PID reference
source
10
10: Pressure setting of dedicated function of air
compressor
P09.02
PID feedback
source
8
8: Pressure feedback of dedicated function of air
compressor
P09.08
Final limit of PID
control deviation
0.1
/
P11.15
Speed deviation
detection time
0.0
/
P11.16
Automatic
frequency
reduction during
voltage drop
1
0: Invalid
1: Valid
P13.08
Control
parameter 1
288
0x120
P13.09
Control
parameter 2
5.00
/
P18.00
Air compressor
control mode
1
0: Normal VFD mode
1: Air-compressor control mode
