INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Function description
-35-
Function
code
Name
Description
Default
Modify
P02.09
Mutual inductance of
AM 1
0.1–6553.5mH
Model
depended
○
P02.10
No-load current of AM
1
0.1–6553.5A
Model
depended
○
P02.11
Magnetic saturation
coefficient 1 of iron
core of AM 1
0.0–100.0%
80.0%
◎
P02.12
Magnetic saturation
coefficient 2 of iron
core of AM 1
0.0–100.0%
68.0%
◎
P02.13
Magnetic saturation
coefficient 3 of iron
core of AM 1
0.0–100.0%
57.0%
◎
P02.14
Magnetic saturation
coefficient 4 of iron
core of AM 1
0.0–100.0%
40.0%
◎
P02.15
Rated power of SM 1
0.1–3000.0kW
Model
depended
◎
P02.16
Rated frequency of SM
1
0.01Hz–P00.03 (max. output frequency)
50.00Hz
◎
P02.17
Number of pole pairs of
SM 1
1–50
2
◎
P02.18
Rated voltage of SM 1
0–1200V
Model
depended
◎
P02.19
Rated current of SM 1
0.8–6000.0A
Model
depended
◎
P02.20
Stator resistance of SM
1
0.001–65.535Ω
Model
depended
○
P02.21
Direct-axis inductance
of SM 1
0.01–655.35mH
Model
depended
○
P02.22
Quadrature-axis
inductance of SM 1
0.01–655.35mH
Model
depended
○
P02.23
Counter-emf constant
of SM 1
0–10000
350
○
P02.26
Overload protection
selection of motor 1
0: No protection
1: Normal motor (with low speed
compensation)
2
◎
