4-32
Ship Speed Range
・Function・ The maximum display value of the graph is set.
Setting value: [ 5 10 15 20 25 30 40 ] kn
The setting of the time axis is common with current/depth graph.
Operation Standard Menu: “Graph Picture setting” menu/Ship speed range: 10 kn
Selection Frame Menu: “Ship Speed graph” menu/Ship speed range: 10 kn
Ship Speed Graph
・Function・ When OFF is selected, the ship speed graph display can be erased.
Setting value: [ Display ON OFF ]
The amount where the ship speed graph disappeared expands current/depth graph and is
displayed.
Operation Standard Menu: “Graph Picture setting” menu/Ship Speed Graph: Display ON
4.5.3 Water Temperature Graph Setting
・Function・ The elapsed time of the water temperature is displayed in the graph. (*1)
The displayed range of the water temperature can be changed by a set menu.
The water temperature graph is set by measure setting/alarm and graph setting (*2) of the
menu.
In the setting of alarm and the graph, a center temperature in the water temperature graph
and width (range) in the water temperature graph are set.
The setting of the time axis is common with current/depth graph.
Operation Standard Menu: [MENU] key/Menu screen/Measure setting ≫ /[ENT] key/“Measure
setting” menu/Alarm and Graph setting≫/“Alarm and Graph setting” menu/
Temperature Graph Center and Temperature Graph Width
Selection Frame Menu: [□] key/ Enclose “Water temperature graph” with the frame
/[MENU] key/“Water temperature alarm and graph” menu/Temperature Graph Center and
Temperature Graph Width
Water Temperature Display
・Function・ The water temperature graph display can be erased by selecting OFF.
Setting value: [ Display Non-display ]
The amount where the water temperature graph disappeared expands current/depth
graph and is displayed.
Operation Standard Menu: [MENU] key/Menu screen/Picture Setting≫/ [GRAPH] screen ≫/[ENT]
key/“Graph Picture setting” menu/Temperature display: Display ON
*1 It is necessary to connect the water temperature sensor for the display of the water temperature graph.
*2 The water temperature graph is on current 1, current 2, and the [GRAPH] screen, and the graph setting is common.
Measure setting/Alarm and Graph setting: Refer to 4.1.8 “Setting of Measurement Alarm and Water Temperature Graph”
Water Temperature Center and Water Temperature Graph Width.
