7.2 Initial Setting
Service person must execute this paragraph after confirming the normal performance by the check after
equipment is installed.
Do not adjust it excluding special service person.
It might cause operation to become unstable if a wrong setting is
The following content can be done by the initialization menu.
･Display of equipment operation outline
･The display of a set menu when installing: Refer to 7.1 “Setting When Installing”.
･Mode selection of Measurement/Dummy
･Display of software version information
･Copy and Erase of storage data saved on CF card
7.2.1 How to Open the Initial Setting Menu
1. The main menu is opened pushing the MENU key.
2. Initial setting≫ is selected from the menu items, the [ENT] key is pushed, and the initial
setting menu is displayed.
3. The [MENU] key is pushed again or Menu Display/Exit is selected, the [ENT] key is
pushed, and it ends.
7.2.2 Outline of the Operation
Outline of the Operation
・Function・ When ≫ is selected, and the [ENT] key is pushed, it is display as for "Manual excerpt
version" of the following content.
1. Name and function of keyboard each part ----------------------- Refer to 2.1.
2. Flow of the operation -------------------------------------------------- Refer to 3.1.
3. Menu composition ①Standard menu composition ----------- Refer to 3.2.1.
②Selection frame menu composition - Refer to 3.2.2.
4. Ready for operation ---------------------------------------------------- Refer to 3.3.
5. Measurement alarm display ----------------------------------------- Refer to 5.1.
6. Warning display --------------------------------------------------------- Refer to 9.1.
Operation Standard Menu: “Initial setting” menu/Outline of the operation≫/[ENT] key/
Display "Manual excerpt version"
To Next Page
