11-5
11.1.4 Mechanical Specification
1) Construction/Mass LCD Monitor : Desk-top, Flush-mount/3.7kg/IP45
/
Waterproof grade Signal processor : Wall hanging/16kg/IP01
Keyboard : Desk-top, Flush-mount /1kg/IP22
Transducer : Submerged/25kg (include cable)/IP68
2) Outline Size LCD Monitor : 298mm (H) x 395mm (W) x 65mm (D)
(Not included brightness knob and optional stand.)
Signal processor : 423.5mm (H) x 326.8mm (W) x 257.4mm (D)
(Not included Installation part and cable support.)
Keyboard : 123mm (H) x 290mm (W) x 57mm (D)
(Depth at embedding: 41mm)
Transducer
CFT-068B : 120mm (H) x 183mm (W) x 450mm (L)
(Not included cable sealing off part and with 25m cable)
CFT-067B : 108mm (H) x 133mm (W) x 394mm (L)
(Not included cable sealing off part and with 25m cable)
