4-16
4.1.26 Filter Setting 5:L0/L1/L2/L3/L4/L5/L6/L7/L8/L9
Function It is a menu for servicemen.
Adjust the settings. When Set of filter setting1 is A or B
Use the L8 position usually.
Operation
MENU MEASURE SETTING FILTER SETTING 5 = L0 / L1 / L2 / L3 / L4 / L5 / L6 / L7 / L8 / L9
About Filter Setting 5
0～9 :
Setting of Filter setting1 only when A or B, Adjustment is enabled.
Adjust the threshold of signal detection level.
The smaller the value, to detect the low levels signal.
The smaller the number, it can be expected to display a trend of more deep.
But, The influence of noise and interference,
There is a risk measurement error is large.
Use the L8 position usually.
(reference)
By the set to 7, it can be expected to measure the few m deep.
If the seven smaller configuration, Measurements of the deeper is unreliable.
4.1.27 Filter Setting 6:M0/M1/M2/M3/M4/M5/M6/M7/M8/M9
Function It is a menu for servicemen.
Adjust the settings. When Set of filter setting1 is B or C
Use the M5 position usually.
Operation
MENU MEASURE SETTING FILTER SETTING 6 = M0 / M1 / M2 / M3 / M4 / M5 / M6 / M7 /
M8 / M9
About Filter Setting 5
0～9 :
Setting of Filter Setting1 will be effective to adjust only when the B or C.
When the amount of information is less shallow sea and/or when the low current speed,
Adjustment the response and stability of the current calculation.
Lower the setting, you can expect that the response is improved.
But, There is a possibility that measurement error increases.
Use the M5 position usually.
* Standard setting is current measurement operation of the stability-oriented.
When the configuration changes to the stability-oriented → response emphasis on,
Please refer to the reference set value 7-3) section.
