JRC JLN-652 User Manual

4-38
▼
▼
4.6.5 Depth Range Setting
This section is described 1)Depth range setting of FISH screen and 2)The range of depth
is allocated to a numeric key.
[FISH] screen: Depth Range Setting
・Function・ It changes within the range of depth corresponding to each key on the [FISH] screen when
[numerical value] key on the keyboard is pushed. (*1)
Operation For instance, if [5] of [numerical value] key is pushed by setting table below 4.6.3, the
range of depth becomes 160m.
Refer to table below 4.6.3 for the default of the [numerical value] key and the range of
depth.
Allocating Numeric Key to the Depth Range
・Function・ Ten [numerical value] keys (1-9,0) are made to correspond within the range of depth on
the [FISH] screen and it allocates.
Operation "[FISH] screen depth setting menu" is displayed pushing [DEPTH] key at the [FISH] screen.
(*2)
The range of depth of each number of ten [numerical value] keys "1,2,････9,0" on the
keyboard is set on the depth setting menu screen.
For instance, when you allocate the range of 180m to [5] of [numerical value] key.
1) The [FISH] screen depth setting menu is opened pushing [DEPTH] key (*3).
2) Five [5] is selected with ▲/▼ cursor.
3) It is input with [numerical value] key on the keyboard as " 180 " (10m unit)(selection (*4)
of the unit).
4) It fixes it pushing [ENT] k ey.
5) It ends pushing [DEPTH] k ey.
Table 4.6.3 [FISH] Screen: Depth Range Setting Menu
Fish-Finder Depth Range Setting: Setting with Numerical Key
1
20 ｍ
2 40 ｍ
3
80 ｍ
4
120 ｍ
5
160 ｍ
6
200 ｍ
7
250 ｍ
8
300 ｍ
9
350 ｍ
0
400 ｍ
*1 The range in the graph doesn't change excluding the [FISH] screen even if [numerical value] key on the keyboard is pushed.
Set it by the range menu of each screen.
*2 The depth range on the [FISH] screen can be set from the selection frame menu.
Selection Frame Menu: [□] key/ Enclose “[FISH] display screen” with the frame /[MENU] key/"Fish Finder display”
menu/Range setting≫ /“Fish Finder Depth Range setting” menu
*3 When the [DEPTH] key is pushed excluding the [FISH] screen, "Current Depth setting" menu is displayed.
*4 The unit within the range of depth can be selected from "m/fathom". Refer to 7.1.3 “Depth Unit”.
After setting
１６０
→
１８０ ｍ
▼▼▼▼▼▼▼▼▼▼
