JRC JLN-652 - Alarm Display, Stopping of Alarm Sound and Adjusting Volume; Setting of Display Color in Shoal of Fish Image and Echo Graph

3-13
3
3.3.4 Alarm Display, Stopping of Alarm Sound and Adjusting volume
1) The alarm display and the alarm sound are stopped when alarm is
generated, and it is canceled an alarm.
Push the BUZZER key. The alarm display and the alarm sound stop.
2) The alarm sound volume is adjusted.
1 Push the [MENU] key. The main menu is displayed.
2 The screen Alarm sound volume is selected from the main menu.
3 OFF or 1-3 is selected from the [Alarm sound volume], and it fixes with the [ENT] key.
Setting Value
OFF
１
２
３
Sound Volume
Sound OFF
Low
Medium
High
3.3.5 Setting of Display Color in Shoal of Fish Image and Echo Graph
The shoal of fish image and the echo graph can selecting set the display color respectively.
1) The display color of the shoal of fish image on the [FISH] screen is
set.
1 Push the [MENU] key. The main menu is displayed.
2 The screen Picture setting is selected from the main menu.
3 [FISH≫] is selected from "Picture setting", and "Fish Finder Picture setting" is displayed
with the [ENT] key.
4 A, B, C or D is selected from the Color, and it fixes with the [ENT] key.
Setting Value
Ａ
Ｂ Ｃ Ｄ
Color
Arrangement
16 Color
Blue system
color
16 Color
Green
system color
16 Color
Light color
8 Color
Blue system
color
2) The display color of echo graph on the [CURR] screen is set.
1 Push the [MENU] key. The main menu is displayed.
2 The screen Picture setting is selected from the main menu.
3 [CURR ≫ ] is selected from "Picture setting", and "Tidal Current Picture Setting" is
displayed with the [ENT] key.
4 A, B, C or D is selected from the Color, and it fixes with the [ENT] key.
Setting Value
Ａ
Ｂ Ｃ Ｄ
Color
Arrangement
16 Color
Blue system
color
16 Color
Green
system color
16 Color
Light color
8 Color
Blue system
color
