3-16
Introduce reference values for setting when not using simple setting
The following configuration changes is
the setting that priority to the response compared to the standard setting.
This setting is the setting that assumes as much follow-up and JLN628(std.. or short.).
Adjustment of response (stability) is, please go tide ava. processing time 1,2.
BTM ADJUSTMENT = +2 0 (Adjusted in accordance with change of tide process.)
TIDE PROCESS = J3 J3 or J4+ (Adjusted in accordance with
change of response-oriented)
TIDE AVG. PROCESSING TIME 1 = 6 8 (Time constant filter 8: about 240s)
TIDE AVG. PROCESSING TIME 2 = 7 5 (Same kind of filter operation as the 628.)
TIDE RESPONSE TIME 1 = 6 3 (Same kind of filter operation as the 628.)
TIDE RESPONSE TIME 2 = 0 (Standard setting)
FILTER SETTING 1 = B1 (Standard setting)
FILTER SETTING 2 = K3 (Standard setting)
FILTER SETTING 6 = M5 M3 (Same kind of filter operation as the 628.)
Below, change depending on the preferences and circumstances.
TIDE DATA UPDATE TIME = MOMENT FAST (It reduces the variation of the display value.)
The following configuration changes is
the setting that priority to extreme importance to response-oriented.
Response is faster than the standard set of JLN628.
However, in order to easily influenced by the disturbance, the variation will increase.
Adjustment of response (stability) is, please go tide ava. processing time 1,2.
( The following is related to Ver.3.1.1.21.
Depending on the version of the software, the standard value and the setting item,
there is a different thing. )
BTM ADJUSTMENT = +2 0 (Adjusted in accordance with change of tide process.)
TIDE PROCESS = J3 J3 or J4+ (Adjusted in accordance with
change of response-oriented)
TIDE AVG. PROCESSING TIME 1 = 6 6～9 (Time constant filter about 20s ～ 120s)
TIDE AVG. PROCESSING TIME 2 = 7 Short (Same kind of filter operation as the 628.)
TIDE RESPONSE TIME 1 = 6 Short (Same kind of filter operation as the 628.)
TIDE RESPONSE TIME 2 = 0 -3 (Same kind of filter operation as the 628.)
FILTER SETTING 1 = B1 (Standard setting)
FILTER SETTING 2 = K3 K1 (Adjusted in accordance with change of response-oriented)
FILTER SETTING 6 = M5 M1 (Adjusted in accordance with change of response-oriented.)
Below, change depending on the preferences and circumstances.
TIDE DATA UPDATE TIME = MOMENT FAST (It reduces the variation of the display value.)
Filter settings will mutually influence each item each other.
Therefore, in the above-mentioned two settings, different response time for the setting of the
TIDE AVG. PROCESSING TIME 1.
