Item Symbol Display Function
124 Steer angle display
t
Indicates the current steer angle with
reference to the centre position.
124
Rail guidance: Steer angle display is replaced by the following symbols:
"Truck guided (with
aisle detection)"
o
Symbol lights up as soon as the truck is
automatically guided and has received an
aisle signal.
"Truck guided
(without aisle
detection)"
Symbol lights up as soon as the truck is
automatically guided and has not
received an aisle signal.
– Continue driving industrial truck along
the narrow aisle.
– As soon as the industrial truck
receives an aisle signal, the "Truck
guided (without aisle detection)"
symbol is replaced by the "Truck
guided (with aisle detection)" symbol.
98
04.19 en-GB
