Item Symbol Display Function
124
Wire guidance: Steer angle display is replaced by the following symbols:
“Acquisition in
progress”
o
Symbol lights up as soon as the truck has
acquired the guide wire.
"Truck guided (with
aisle detection)"
Symbol lights up as soon as the truck is
automatically guided on the wire and has
received an aisle signal.
"Truck guided
(without aisle
detection)"
Symbol lights up as soon as the truck is
automatically guided on the wire and has
not received an aisle signal.
– Continue driving industrial truck along
the narrow aisle.
– As soon as the industrial truck
receives an aisle signal, the "Truck
guided (without aisle detection)"
symbol is replaced by the "Truck
guided (with aisle detection)" symbol.
"Truck not guided“
Symbol is lit as soon as the industrial
truck has been turned off and on again
with the key switch on the guide wire.
– Continue driving industrial truck along
the narrow aisle.
– "Truck not guided" symbol is replaced
by the "Acquisition in progress"
symbol.
– As soon as the industrial truck has
acquired the guide wire and received a
valid aisle signal, the "Truck guided
(with aisle detection)" symbol is lit.
“Deviation from
guide wire”
Symbol lights up as soon as the truck
moves away from the guide wire and
therefore from automatic guidance.
