Symbol and meaning Function
Personal Safety System (PSS)
"Protection field
infringement" symbol
o
– Indicates that there are persons/
obstacles in the protection field of the
personal protection system in the
narrow aisle, see page 245.
– Indicates missing activation frequency
for the stationary personal safety
system.
The truck brakes to a halt.
“Protection field
infringement" button
o
Overrides the protective function and
enables creep speed (2,5 km/h) if there
is sufficient distance from the obstacle,
see page 245.
The travel function is controlled with the
accelerator pedal and the travel direction
switch.
"Warning field
infringement" symbol
o
Indicates that there are people /
obstacles in the warning field of the
personal protection system in the narrow
aisle, see page 244.
The truck brakes. During this time the
travel speed is restricted to creep speed
(2,5 km/h).
“Acknowledge cycle test”
symbol
o
Indicates that the cycle test of the
personal protection system must be
performed (every 24 hours), see
page 243.
The truck brakes. During this time the
travel speed is restricted to creep speed
(2,5 km/h).
“Acknowledge cycle test”
button
o
Automatically starts the cycle test.
Symbol and meaning Function
Attachment, fork tilt, special attachment
"Fork tilt" symbol
o
Indicates that fork tilt is possible.
“Fork tilt” key
o
Activates fork tilt.
This hydraulic function is controlled with
"hydraulic functions" control lever.
"Special attachment"
symbol
o
Indicates that the special attachment can
be operated.
“Special attachment” key
o
Activates special attachment operation.
This hydraulic function is controlled with
"hydraulic functions" control lever.
111
04.19 en-GB
