3.3.3 Control panel longitudinal adjustment
Z
The control panel (118) can be adjusted horizontally by 200 mm.
CAUTION!
An unsecured control panel can cause accidents and injury
An unsecured control panel can slide during operation and result in accidents.
u
The control panel must be locked in place when the truck is in operation.
u
Do not adjust the control panel during operation.
Procedure
• Hold onto the control panel (118).
• Pull the longitudinal adjusting lever (147)
up.
• Set the control panel (118) to the
required position.
• Push the control panel to the right,
see arrow direction "A".
• Pull the control panel to the left, see
arrow direction "B".
• Release the longitudinal adjusting
lever (147) and lock the control
panel (118) in position.
The control panel (118) has now been adjusted horizontally.
147
118
126
04.19 en-GB
