Lift cut-out when referencing
WARNING!
An extended mast can cause accidents
The lift cutout is an auxiliary function designed to support the operator which
however does not release him from his responsibility to stop hydraulic operations
e.g. when confronted with an obstacle.
u
When the lift cutout has been de-activated the truck must be operated with extra
care in order to detect obstacles when the mast is extended.
u
Stop lifting before you reach the obstacle.
Procedure
• Pressing the “lift cut-out override” button (104) below the "lift cut-out" symbol (161)
disables the lift cut-out.
• The hydraulic functions are controlled with the "hydraulic functions" control lever,
see page 171.
148
04.19 en-GB
