Jungheinrich EFX 413 User Manual

4.14.1 Attachment traverse
Requirements
– Prepare the truck for operation, see page 138 or see page 139.
Procedure
• Do not press the deadman button (20).
• Press and hold down on the "Attachment traverse" button (120).
• Traverse attachment to the right:
• Turn the "Hydraulic functions" control lever (113) clockwise.
• Traverse attachment to the left:
• Turn the "Hydraulic functions" control lever (113) anti-clockwise.
Z
The traverse speed is in proportion to how far the "Hydraulics function" control
lever (113) is rotated.
The attachment moves to the right or left.
Z
If the attachment is not in the home position, you can only travel, lift or lower at a
reduced speed, see page 192.
113
20
120
119
177
04.19 en-GB
