CAUTION!
Hand / arm trapping hazard
There is a risk of trapping when you close the battery cover and fit the side panels,
battery retainers, battery locks and battery.
u
Make sure there is nothing between the parts mentioned above and the truck
when you fit the battery, retainers and side panels.
u
Make sure there is nothing between the battery cover and the truck when you
close the battery cover.
WARNING!
Collision hazard when operating the truck
Collisions with personnel and equipment can result if the truck is operated with open
panels and covers.
u
Do not operate the truck unless the panels and covers are closed and properly
locked.
Battery installation
Requirements
– Park the truck securely, see page 191.
– Expose the battery, see page 76.
Tools and Material Required
– Battery roller stand
Procedure
• Position the battery roller stand with the battery (99) in front of the battery
compartment in such a way that the battery (99) can be safely pushed into the
truck's battery compartment.
Z
The battery retainers (102,100) can swap positions. The battery retainers
(102,100) can be inserted in either the left- or right-hand side of the truck’s
chassis.
Insert the battery retainer (100) opposite the entry side in the chassis (see arrow
direction "D").
• Undo the battery lock on the battery roller stand.
84
04.19 en-GB
