SRX1600 Chassis
IN THIS SECTION
Chassis Physical Specicaons for SRX1600 | 11
Front Panel of the SRX1600 | 12
Rear Panel of the SRX1600 | 13
Chassis Status LEDs | 15
Management Port LEDs | 16
Network Port LEDs | 17
The SRX1600 rewall chassis is a rigid sheet metal structure that houses all the other hardware
components.
Chassis Physical Specicaons for SRX1600
The SRX1600 rewall has a 1-U form factor and you can be install it in a standard 19 in. rack. Table 4 on
page 11 summarizes the physical specicaons of the SRX1600.
Table 4: Physical
Specicaons of SRX1600
Model Height Width Depth Weight
SRX1600 1.74 in. (4.42 cm) 17.28 in. (43.89 cm) 18.20 in. (46.23 cm) 15.90 lb (7.2 kg)
NOTE: We ship the SRX1600 with only one power supply unit (PSU). The weight of an SRX1600
device congured with 2 PSUs is 17.86 lb (8.1 kg).
