Table 5: Components on the Front Panel of the SRX1600 (Connued)
Callout Component (Label on the Chassis) Descripon
7 Chassis LEDs Indicate component and system status
and troubleshoong informaon at a
glance.
8 Power buon Power buon
9 Pull tab Contains the CLEI code and serial
number of the device
10 RESET Reset buon. To reset the system,
press and hold the RESET buon for
around 250 ms.
11 Console port (CON) You can connect a laptop to the
SRX1600 to manage the CLI. The port
uses an RJ-45 serial connecon and
supports the RS-232 (EIA-232)
standard.
12 Claim code You can use the QR code to claim and
onboard your device to Juniper
Security Director.
Rear Panel of the SRX1600
Figure 2 on page 14 shows the rear panel of the AC variant of an SRX1600 rewall.
