Cable Specicaons and Pinouts for SRX1600
IN THIS SECTION
Transceiver Support for SRX1600 | 39
RJ-45 Connector Pinouts for the SRX1600 Firewall Management Port | 39
RJ-45 Connector Pinouts for the SRX1600 Firewall Console Port | 40
Transceiver Support for SRX1600
Use the Hardware Compability Tool to nd informaon about the pluggable transceivers and the
supported connector types of your Juniper Networks device. The tool also documents the opcal and
cable characteriscs, where applicable, for each transceiver. You can search for transceivers by product,
and the tool displays all the transceivers supported on that device. You can also search by category,
interface speed, or type. The list of supported transceivers for the SRX1600 is located at hps://
apps.juniper.net/hct/product/.
CAUTION: If you face a problem running a Juniper Networks device that uses a third-
party opc or cable, the Juniper Networks Technical Assistance Center (JTAC) can help
you diagnose the source of the problem. Your JTAC engineer might recommend that
you check the third-party opc or cable and potenally replace it with an equivalent
Juniper Networks opc or cable that is qualied for the device.
RJ-45 Connector Pinouts for the SRX1600 Firewall Management Port
The port on the front panel labeled MGMT is a 10/100/1000-Mbps Ethernet RJ-45 port that accepts an
Ethernet cable for connecng the services gateway to a management LAN (or other device that
supports out-of-band management). Table 26 on page 40 describes the RJ-45 connector pinouts for
the Ethernet port.
