Front Panel of the SRX1600
Figure 1 on page 12 shows the front panel of an SRX1600 rewall.
Figure 1: Front Panel Components of the SRX1600
Table 5 on page 12 lists and describes the front panel components of the rewall.
Table 5: Components on the Front Panel of the SRX1600
Callout Component (Label on the Chassis) Descripon
1 Ethernet ports Sixteen 1 GbE ports
2 SFP28 ports Two 1/10/25 GbE SFP28 MACsec
ports for network trac
3 SFP+ ports Four 1/10 GbE SFP+ MACsec ports for
network trac
4 Chassis cluster ports (HA) Two 1 GbE SFP chassis cluster control
CTL ports with MACsec support
5 Management port (MGMT) 1 GbE RJ-45 port
6 USB port One USB 3.0 Type A port that accepts
a USB storage device
