Juniper SRX1600 - RJ-45 Connector Pinouts for the SRX1600 Firewall Console Port

Table 26: RJ-45 Connector Pinouts for SRX1600 Firewall Management Port
Pin Signal
1 TX+
2 TX-
3 RX+
4 Terminaon network
5 Terminaon network
6 RX-
7 Terminaon network
8 Terminaon network
RJ-45 Connector Pinouts for the SRX1600 Firewall Console Port
The port on the front panel labeled CON is an asynchronous serial interface that accepts an RJ-45
connector. Table 27 on page 40 describes the RJ-45 connector pinouts for the console port.
Table 27: RJ-45 Connector Pinouts for the SRX1600 Firewall Console Port
Pin Signal Descripon
1 RTS Request to Send
2 DTR Data Terminal Ready
40
