Juniper SRX1600 - Page 48

Table 27: RJ-45 Connector Pinouts for the SRX1600 Firewall Console Port (Connued)
Pin Signal Descripon
3 TXD Transmit Data
4 Ground Signal Ground
5 Ground Signal Ground
6 RXD Receive Data
7 DSR/DCD Data Set Ready
8 CTS Clear to Send
41
