Juniper SRX1600 - Page 4

Clearance Requirements for Hardware Maintenance of the SRX1600 | 36
Rack Requirements for the SRX1600 | 37
Cable Specicaons and Pinouts for SRX1600 | 39
Transceiver Support for SRX1600 | 39
RJ-45 Connector Pinouts for the SRX1600 Firewall Management Port | 39
RJ-45 Connector Pinouts for the SRX1600 Firewall Console Port | 40
4
Inial Installaon and Conguraon
SRX1600 Installaon Overview | 43
Unpack the SRX1600 | 43
Tools and Parts Required to Unpack the SRX1600 | 43
Unpack an SRX1600 | 44
Verify Parts Received with the SRX1600 | 44
Install the SRX1600 in a Rack | 45
Mount your Device by Using the JNP-4P-TL-1RU-RMK Rack Mount Kit on a Square Hole 4-Post
Rack | 46
Mount your Device by Using the JNP-4P-TL-1RU-RMK Rack Mount Kit on a Threaded-Hole 4-
Post Rack | 49
Connect the SRX1600 to Power | 55
Connect Earth Ground to the SRX1600 | 55
Connect AC Power to the SRX1600 | 57
Connect DC Power to the SRX1600 | 59
Power O the SRX1600 | 61
Connect the SRX1600 to External Devices | 62
Connect Your Device to a Network for Out-of-Band Management | 63
Connect Your Device to a Management Console | 63
Congure Junos OS on the SRX1600 | 64
Congure the SRX1600 Using J-Web | 65
Congure the SRX1600 using Juniper Security Director Cloud | 66
