DCE80-100E
Technical Handbook
Drive axle Kessler
Service
18
P.Group 40
TDCE01
04GB
Installation of hub reduction
1. Press the spacer wahser (1) onto the spindle and seal with
LOCTITE 270.
2. Push the sun gear (2) onto the spindle and secure with the
lock ring (3). Push the input shaft into the hub so that the
spacer washer, sun gear, and lock ring are closely flush with
each other.
