OPERATOR'S STATION
1-83
yTemperature Control Switch (9)
Sets the air temperature in the range of 18 to 32.0 °C (65 to
90 °F) in the MANUAL and AUTO modes. Temperature can
be set by 0.5 °C (0.9 °F) increments. The set-temperature is
displayed on the LCD (8) center.
x Increasing Temperature
Each time the top side mark “
” on temperature control
switch (9) is pressed, the set-temperature is increased by
0.5 °C (0.9 °F) increments.
x Decreasing Temperature
Each time the bottom side mark “
” on temperature
control switch (9) is pressed, the set-temperature is
decreased by 0.5 °C (0.9 °F) increments.
x Temperature Mode Change (Centigrade Q Fahrenheit)
Press both “
” and “ ” marks on the temperature
control switch for longer than 5 seconds at the same
time to change the temperature mode (Centigrade Q
Fahrenheit). (Unit in temperature mode is abbreviated.)
Temperature Mode Display on LCD
Centigrade 18.0 to 32.0
Fahrenheit 63 to 91
MNDB-01-011
98
