KCM 70Z7 - Page 350

To Next Page

To Previous Page

MAINTENANCE

7-109

1. Front axle mounting bolt

Bolt dia. mm (in) 24 (0.9)

Quantity 8

2. Rear axle support mounting bolt

Bolt dia. mm (in) 24 (0.9)

Quantity 8

3. Wheel rim mounting bolt

Bolt dia. mm (in) 24 (0.9)

Quantity 60

M4GB-07-124

M4GB-07-127

M4GB-07-125

MNEC-07-052
