MAINTENANCE
7-110
4. Propeller shaft mounting bolt
Bolt dia. mm (in) 12 (0.5)
Quantity 20
NOTE: Apply LOCTITE#262 or equivalent.
5. Propeller shaft support bearing mounting bolt
Bolt dia. mm (in) 20 (0.8)
Quantity 2
NOTE: Apply LOCTITE#262 or equivalent.
6. Transmission mounting bolt: Bracket
Bolt dia. mm (in) 20 (0.8)
Quantity 4
NOTE: Apply LOCTITE#262 or equivalent.
M4GB-07-017
MNEC-07-053
MNDB-07-010
To Next Page
