MAINTENANCE
7-111
7. Transmission mounting bolt: Cushion rubber
Bolt dia. mm (in) 18 (0.7)
Quantity 2
NOTE: Apply LOCTITE#262 or equivalent.
8. Engine mounting bolt: Bracket
Bolt dia. mm (in) 12 (0.5)
Quantity 6
NOTE: Apply LOCTITE#262 or equivalent.
9. Engine mounting bolt: Cushion rubber
Bolt dia. mm (in) 18 (0.7)
Quantity 2
NOTE: Apply LOCTITE#262 or equivalent.
MNEC-07-093
MNEC-07-054
MNEC-07-093
