MAINTENANCE

7-112

10. Muffler mounting bolt

Bolt dia. mm (in) 10 (0.4)

Quantity 8

11. Counterweight mounting bolt

Bolt dia. mm (in) 30 (1.2)

Quantity 4

12. Top center pin upper flange lock

Bolt dia. mm (in) 16 (0.6)

Quantity 7

MNEC-07-068

MNDB-07-009

MNDB-07-013
