MAINTENANCE

7-113

13. Bottom center pin lock

Bolt dia. mm (in) 16 (0.6)

Quantity 1

14. Loader front pin lock

70Z7 70TM7

Bolt dia. mm (in) 16 (0.6) 12 (0.5) 16 (0.6) 12 (0.5)

Quantity 9 4 14 22

70Z7

70TM7

M4GB-07-180

MNEC-07-058

M4GB-07-137

MNEC-07-006
