MAINTENANCE
7-114
15. Steering cylinder pin lock
Bolt dia. mm (in) 12 (0.5)
Quantity 4
16. Radiator frame mounting bolt
Bolt dia. mm (in) 16 (0.6)
Quantity 6
NOTE: Apply LOCTITE#262 or equivalent.
17. Radiator mounting bolt
Bolt dia. mm (in) 8 (0.3)
Quantity 2
18. Intercooler mounting bolt
Bolt dia. mm (in) 8 (0.3)
Quantity 1
MNEC-07-095
MNEC-07-096
MNEC-07-097
MNEC-07-004
