MAINTENANCE

7-115

19. Oil cooler mounting bolt

Bolt dia. mm (in) 10 (0.4)

Quantity 2

20. Torque converter cooler mounting bolt

Bolt dia. mm (in) 10 (0.4)

Quantity 4

21. Air conditioner condenser mounting bolt

Bolt dia. mm (in) 8 (0.3)

Quantity 4

MNEC-07-098

MNEC-07-099

MNEC-07-097
